ABB EK1000-40-22-AP Contactor 6 makers, 2 breakers 1 pc(s)

An ABB circuit breaker, model EK 1100, with multiple connection terminals. Used for controlling and protecting electrical circuits.
Product type
Contactor
No. of pins
4-pin
Connection
Terminal strip
Type
EK1000-40-22-AP
Contact type
6 makers
2 breakers
Datasheet (PDF)
EAN:
Part number:
Item no:
Unavailable
Sales and shipping:
Conrad ElectronicTerms & Conditions
Report legal concerns

Technical specifications

Product type

Contactor

Type

EK1000-40-22-AP

No. of pins

4-pin

Contact type

6 makers

2 breakers

Auxiliary contact type

6 makers

Control voltage (min.)

380 V AC

Control voltage (max.)

400 V AC

Control voltage range

380 - 400 V AC

Switching voltage (max.)

1000 V AC

Permanent current (max.)

1000 A

Connection

Terminal strip

Content

1 pc(s)

FALSE

4

0

2

2

1000 A

380-400 V

440-440 V

Rail connection

AC

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 3112853 ABB EK1000-40-22-AP Contactor 6 makers, 2 breakers 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3112853 ABB EK1000-40-22-AP Contactor 6 makers, 2 breakers 1 pc(s)

Description

The AC-operated 4-pole EK550 contactors are mainly used for switching motors, not or slightly inductive power circuits up to 1000V AC and 600V DC. All subsequently mountable NC auxiliary contacts are implemented as mirror contacts in accordance with IEC60947-5-1 Annex L. Other accessories such as wiring aids and locking links, among others, complete the range.
