ABB EPD24-TB-101-1A 2CDE601101R2001 Safety relay
Product type
Safety relay
Operating voltage
24 V
Type
EPD24-TB-101-1A
Dim
(L x W x H) 83 x 12.5 x 80 mm
Width
12.5 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Type
EPD24-TB-101-1A
- Product type
Safety relay
- Operating voltage
24 V
- Dim
(L x W x H) 83 x 12.5 x 80 mm
- Width
12.5 mm
- Height
80 mm
- Length
83 mm
DIN rail (top hat rail) 35 mm
Grey
12.5 mm
80 mm
83 mm
24 V
0-50 °C
V0
FALSE
Screw connection
Screw connection
Other
Pluggable
LED
8-8 V
1
AC
6-6 mm²
10-10 mm²
10-10 mm²
4-4 mm²
Thermoplastic
1 A
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3099031 ABB EPD24-TB-101-1A 2CDE601101R2001 Safety relay
User & Safety Instructions
User & Safety Instructions 3099031 ABB EPD24-TB-101-1A 2CDE601101R2001 Safety relay
Description
The EPD24 protection devices expand the ABB product portfolio
Of the series installation devices around electronic overcurrent protection modules
For selective protection of 24 V DC load circuits.
This security is provided by a combination
From active electronic current limitation in the
Short-circuit and an overload shut-down starting from 1.1 x IN
helicopter.
This text is machine translated.
Of the series installation devices around electronic overcurrent protection modules
For selective protection of 24 V DC load circuits.
This security is provided by a combination
From active electronic current limitation in the
Short-circuit and an overload shut-down starting from 1.1 x IN
helicopter.
This text is machine translated.
