ABB NF53E-11 Switch 3 makers, 5 makers 24 V 3 A + surge protection Piece 1 pc(s)
Product type
Switch
No. of pins
8-pin
Nominal voltage
24 V
Current load
3 A
Connection
Axial screw terminal
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Packaging type
Piece
- Product type
Switch
- Type
NF53E-11
- No. of pins
8-pin
- Contact type
3 makers
5 makers
- Auxiliary contact type
5 makers
- Nominal voltage
24 V
- Control voltage (max.)
24 V DC
- Control voltage range
24 V DC (max)
- Permanent current (max.)
3 A
- Current load
3 A
- Features
+ surge protection
- Mounting type
Screws
- Connection
Axial screw terminal
- Content
1 pc(s)
DIN-rail/screw
5
3
0
24-60 V
24-60 V
20-60 V
FALSE
AC/DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2317746 ABB NF53E-11 Switch 3 makers, 5 makers 24 V 3 A + surge protection Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2317746 ABB NF53E-11 Switch 3 makers, 5 makers 24 V 3 A + surge protection Piece 1 pc(s)
Description
The 8-pin LF contactor relays are used for switching auxiliary and control circuits (positively driven contacts available). They have an electronic coil interface that allows a wide control voltage range and can handle large control voltage fluctuations. LF contactor relays have an integrated surge protection and do not require any additional extinguishing elements. The types with coil code -11 are not suitable for connection to 24VDC PLC outputs.
This text is machine translated.
This text is machine translated.
