ABB VB6A-30-10-80 Switch 3 makers 4 kW 220 V 8.5 A 1 pc(s)

'Switchgear with multiple connections, numbered from 1 to 14. Label 'VB6A-30-10', brand logo top right.'
Product type
Switch
No. of pins
2-pin
Nominal voltage
220 V
Current load
8.5 A
Power
4 kW
Datasheet (PDF)
EAN:
Part number:
Item no:
Unavailable
Sales and shipping:
Conrad ElectronicTerms & Conditions
Report legal concerns

Technical specifications

Product type

Switch

Type

VB6A-30-10-80

No. of pins

2-pin

Contact type

3 makers

Auxiliary contact type

1 maker

Nominal voltage

220 V

Control voltage (min.)

220 V AC

Control voltage (max.)

240 V AC

Control voltage range

220 - 240 V AC

Switching voltage (max.)

4 V AC

Permanent current (max.)

9 A

Current load

8.5 A

4 kW

Mounting type

DIN rail

Connection

Screws

IP20

Width

50 mm

Height

100 mm

Depth

150 mm

Dim

(W x H x D) 50 x 100 x 150 mm

Content

1 pc(s)

Weight

1000 g

96.2

Reversing contactor

57.5 mm

46.7 mm

4 kW

3

0

1

0

8.5 A

8.5 A

TRUE

220-240 V

220-240 V

0-0 V

AC

IP20

Screw connection

690-690 V

690-690 V

2.5-2.5 V

AC

1

1.491

UKCA

yes

Documents & Downloads

Datasheet

Datasheet 2326425 ABB VB6A-30-10-80 Switch 3 makers 4 kW 220 V 8.5 A 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2326425 ABB VB6A-30-10-80 Switch 3 makers 4 kW 220 V 8.5 A 1 pc(s)

Description

Small turning contactors VB/VBC 6 and VB/VBC 7 of 4 and 5.5 kW AC-3 (400 V) stand for a series with very small dimensions and with connection variants in screw, solder pin and flat plug technology. This means that the devices offer a very wide range of applications even under unfavorable space conditions. The mechanically locked reversing contactors switch power circuits of motors with clockwise and anti-clockwise rotation with their AC or DC control. Accessories that can be attached are extinguishing links as well as 2-pole auxiliary switches that can be plugged on the front and a reversing wiring.
