ABN XK3S6DUN XK3S6DUN eHZ cassette Piece 1 pc(s)
EAN:
Part number:
Item no:
Product type
eHZ cassette
Factory colour
Grey
Dim
(L x W x H) 1 m x 170 mm x 38 mm
Weight
3.07 kg
Operating voltage
400 V
Technical specifications
- Product type
eHZ cassette
- Factory colour
Grey
- Dim
(L x W x H) 1 m x 170 mm x 38 mm
- Weight
3.07 kg
- Operating voltage
400 V
- Reading type
Active power
- Nominal voltage range
230 up to 400 V AC
- Mains voltage (max.)
400 V AC
- Mains voltage (min.)
230 V
- Width
170 mm
- Height
38 mm
- Length
1 m
- Current (max.)
63 A
- Current range
63 A (max)
- Type
XK3S6DUN
- Packaging type
Piece
- Effective current range
64 A
170 mm
38 mm
238 mm
50-60 Hz
64 A
Effecive and reactive power
FALSE
0-0 Imp/kWh (kvarh)
230-230 V
400-400 V
63 A
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3461085 ABN XK3S6DUN XK3S6DUN eHZ cassette Piece 1 pc(s)
Description
EHZ cassette kit 16mm², including conductors and terminals for N+PE, for TN-S system Universal length 1 m
