APC USV SMT3000RMI2UNC 3000 VA / 2700 W UPS 3000 VA
EAN:
Part number:
Item no:
Highlights & Details
APC UPS SMT3000RMI2UNC 3000 VA / 2700 W
- Continues to supply power in case of power outage
- Up to 2700 watts of output power
- Overvoltage protection to 320 joules
- 8x C13, 1x C19
- Management: USB, RJ-45 10/100 Base-T , RJ-45 Serial, SmartSlot (AP9631 pre-installed)
Technical specifications
- Product type
UPS
- Nominal power
3000 VA
- No. of outputs
8 x
1 x
- Features
LCD
- Bridging time normal load
11 min
- Bridging time, max load
3.2 min
- Type
USV SMT3000RMI2UNC 3000 VA / 2700 W
- Width
480 mm
- Height
86 mm
- Depth
683 mm
- Weight
44.28 kg
- Operating temperature (T-T)
0 - 40 °C
- Auto-restart
yes
- Storage relative humidity (H-H)
0 - 95 %
- Non-operating altitude
0 - 15000 m
- Battery recharge time
3 h
- Audible alarm(s)
yes
- Output power capacity
3 kVA
- Surge energy rating
320 J
- Rack mount kit
yes
- Resource CD
yes
- SmartSlot
yes
- Hot-swap battery
yes
- Management card included
yes
- Web-based management
yes
- Quick installation guide
yes
- Operating altitude
0 - 3000 m
- Operating relative humidity (H-H)
0 - 95 %
- Products per pallet
8 Stück(e)
- Storage temperature (T-T)
-15 - 45 °C
- Surge protection
yes
- Cold start
yes
- Automatic battery test
yes
- Input operation voltage (max)
302 V
- Input operation voltage (min)
151 V
- Output operation voltage (min)
220 V
- Output operation voltage (max)
240 V
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2893785 APC USV SMT3000RMI2UNC 3000 VA / 2700 W UPS 3000 VA
Description
The Smart-UPS-series by APC protects your critical data through reliable, uninterrupted power supply. The SMT3000RMI2UNC in rack enclosure offers 3000 VA capacity at a maximum output power of 2700 watts. In the event of power failure, the unit ensures an independent power supply for 3 to 11 minutes (100%/50% load).
Intuitive operation, easy management
The LCD display shows the UPS always with important characteristics such as operating mode and efficiency, voltage, frequency and power consumption. The clear menu provides intuitive operation of all functions. Thanks to pre-installed network management card you can manage the system remotely immediately after commissioning. A USB and a Serial RJ45 interface are available for on-site management.
Low maintenance
The sealed lead-acid battery with lined electrolyte is completely maintenance-free. The UPS calculates the expected life span of the battery and also determines premature aging symptoms through regular battery tests. The voltage applied during the charging process is adjusted to the temperature of the battery and thus enables a particularly gentle charging, WAS has a positive effect on the life span.
High efficiency
A high efficiency helps to keep the power consumption and cooling requirement low and thus to protect the environment and the budget.
This text is machine translated.
Intuitive operation, easy management
The LCD display shows the UPS always with important characteristics such as operating mode and efficiency, voltage, frequency and power consumption. The clear menu provides intuitive operation of all functions. Thanks to pre-installed network management card you can manage the system remotely immediately after commissioning. A USB and a Serial RJ45 interface are available for on-site management.
Low maintenance
The sealed lead-acid battery with lined electrolyte is completely maintenance-free. The UPS calculates the expected life span of the battery and also determines premature aging symptoms through regular battery tests. The voltage applied during the charging process is adjusted to the temperature of the battery and thus enables a particularly gentle charging, WAS has a positive effect on the life span.
High efficiency
A high efficiency helps to keep the power consumption and cooling requirement low and thus to protect the environment and the budget.
This text is machine translated.
Scope of delivery
- UPS with network card AP9631
- CD with software
- Country-specific, removable power cable
- User manual
- Documentation CD.
- Rack-mounted carrying rails
- Intelligent UPS-signal cable RS-232
- Temperature sensor;
- USB cable
Hints
This UPS requires a power connection with 16 ampere. If you are unsure, ask your electrician.
