Passive ComponentsResistorsHigh Power Wirewound Resistors

Arcol HS50 1K J HV resistor 1 kΩ 50 W 1 pc(s)

A yellow, cylindrical resistor with the markings 'ARCOL 11-29' and 'HS50 R05 J'.
Product type
HV resistor
Resistance
1 kΩ
Power rating
50 W
Content
1 pc(s)
Width
29.7 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Fast track dispatch on Thu 29 Oct
235 Piece(s)
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 4.79 / piece)
€ 4.79
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

Arcol HS50 1K J 50W Aluminium Clad Resistor

Our service for you

Technical specifications

  • 1.25 kV
Product type

HV resistor

Resistance

1 kΩ

Power rating

50 W

Width

29.7 mm

Height

14.8 mm

Max. temperature

+200 °C

Content

1 pc(s)

Dim

(W x H) 29.7 mm x 14.8 mm

RoHS-compliant

Yes

Type

HS50 1K J

Documents & Downloads

Datasheet

Datasheet 3014067 Arcol HS50 1K J HV resistor 1 kΩ 50 W 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3014067 Arcol HS50 1K J HV resistor 1 kΩ 50 W 1 pc(s)

Description

Features

  • Case Type: Chassis mount|Power Handling: 50W|Resistance: 1000Ω|Temperature Coefficient: 25ppm/°C|Tolerance: 5%|Type: Wirewound aluminium clad|Working Voltage: 1.25kV
