ATEN AV Converter VC182-AT-G [VGA, Jack - HDMI] 1920 x 1080 Pixel
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
ATEN VC182 VGA/Audio-to-HDMI converter with Scaler
- Converts VGA-in HDMI-signals
- Analogue and digital audio transmission
- Improved image quality - Resolutions up to 1080p, 1920x1200
- Scaling function - The Hochleistungs-Skalierer converts the different resolutions of the input signal in the native resolution of the screen; the image aspect ratio is automatically adjusted to ensure an optimum display.
- 3D Deinterlacing - improves the picture quality through the scanning and processing of digital image signals
Technical specifications
- Product type
AV Converter
- Connection type
VGA
Jack
HDMI
- No. of A connectors
1 x
- Type A
D-SUB socket 15-pin
Jack socket 3.5 mm
- No. of B connections
1 x
- Type B
HDMI socket
- Video resolution
1920 x 1080 Pixel
- Cable length
0 mm
- Factory colour
Black
- Connector version
straight
- Version
Converter
- Cable use
AV
- Weight
310 g
- Length
83 mm
- Width
110 mm
- Height
28 mm
- Dim
(L x W x H) 83 x 110 x 28 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1879719 ATEN AV Converter VC182-AT-G [VGA, Jack - HDMI] 1920 x 1080 Pixel
Description
Aten VC 182. Supported Video modes: 1080p. Host Interface: HDB-15, RCA, output interface: HDMI. Product Color: black. Width: 83 mm, Depth: 110 mm, Height: 28 mm
This text is machine translated.
This text is machine translated.
Features
- Built-in high-performance scaling function for optimum picture quality
- Powerful De-Interlacer for interference-free and seamless image playback
- Built-in screen menu for configuration of the image and system parameters
- Integrated, improved filter against noise
- Integrated Color Engine Next Generation - automatic picture and color quality settings and optimization
- Automatically detects graphic input signals
- LED display of the swithed signal sources
- No software required - no compatibility issues, no installation problems
- Device configuration via special device via Mini-USB port
- Supports image formats in 16:9 and 4:3
- Selection possibility for different image resolutions + AC 11
Scope of delivery
- VGA to HDMI converter with scaling function
- 1 x 0 AD 6-1 F 05-26 EC power supply
- Software CD
- User manual.
