ATEN CE690-AT-G DVI, USB Extension via FO cable 20 km
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
ATEN CE690 Keyboard/Video/Mouse (KVM) Switch Rack-mount Black
- Improved graphics quality up to 1920 x 1200 at 60 Hz (24 bit) – you get an excellent, crystal-sharp image with transmission paths of up to 20 km.
- Supports touch screens – connect a touch screen (supports devices up to 10-point multi-touch) and benefit from interactive operating comfort (no additional drivers required)
- Dual-console operation – allows you to operate your system from the local and remote console (USB keyboard, mouse, and monitor)
- Uses fiber optic cables to connect the local and remote device
- This text is machine translated.
Technical specifications
- Keyboard port type: USB
- Mouse port type: USB
- Video port type: DVI-D.
- Rack capacity: 1U
- Supported cable length 20000 m.
- Power consumption (typical): 10.2 W.
- Product type
Extension
- Transfer type
via FO cable
- Interfaces (input)
DVI
USB
- Interfaces (output)
DVI
USB
- Resolution (max.)
1920 x 1200 p
- Range (max.)
20 km
- Factory colour
Black
- Weight
2.24 kg
- Length
21.50 cm
- Width
16.33 cm
- Height
4.18 cm
- Dim
(L x W x H) 21.50 x 16.33 x 4.18 cm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1879791 ATEN CE690-AT-G DVI, USB Extension via FO cable 20 km
User & Safety Instructions
User & Safety Instructions 1879791 ATEN CE690-AT-G DVI, USB Extension via FO cable 20 km
Description
Scope of delivery
- 1x CE690L DVI-KVM extension via fiber optic cable (local device)
- 1x CE690R DVI-KVM extension via fiber optic cable (device for remote station)
- 1x 2L-7D02U individual KVM-cable set (1.8 m)
- 1x LIN6-04U1-V1CG USB-cable (1.8 m)2x 0AD6-1605-24EG Power Supplies
- 1x Mounting Kit
- 1x User's Guide
