ATEN VE1833 HDMI extender HDMI 3840 x 2160 Pixel
EAN:
Part number:
Item no:
Highlights & Details
ATEN VE1833 HDMI extender
- AV-transmitter & receiver 4096 x 2160 pixels black
- Maximum possible transmission range: 40 m.
- 60 Hz
- HDCP
- Wired Ethernet/LAN direct current connection (DC)
- Power source: Direct current
Technical specifications
- Impedance 100 Ohm
- USB-Plug USB Typ-A, USB Typ-B
- Product type
HDMI extender
- Video via
HDMI
- Video resolution
3840 x 2160 Pixel
- No. of USB 2.0 ports
3 x
- Rack mount option
Yes
- Power supply (LOV)
mains-powered
- Factory colour
Black
- Weight
640 g
- Width
146.9 mm
- Height
30 mm
- Dim
(W x H x D) 146.9 x 30 x 169.4 mm
- Depth
169.4 mm
- Display resolution
4096 x 2160 Pixel
- Frame rate
60 Hz
- No. of USB ports
3 x
- HDCP
Yes
- HDR support
Yes
- Material
Metal
- Type
AV-transmitter & -receiver
- Transfer type
Corded
- UKCA
yes
- Operating temperature (T-T)
0 - 40 °C
- Ethernet LAN
yes
- 3.5 mm (1/8-inch) in
yes
- Master (outer) case gross weight
6.69 kg
- 3.5 mm (1/8-inch) out
yes
- Consumer Electronics Control (CEC) support
yes
- Master (outer) case length
500 mm
- DC-in jack
yes
- Bandwidth
18 Gbit/s
- Power consumption (TX)
6.01 W
- Power consumption (RX)
7.09 W
- Firmware upgradeable
yes
- Master (outer) case height
283 mm
- Master (outer) case width
232 mm
- Bandwidth
600 MHz
- Operating relative humidity (H-H)
0 - 80 %
- Storage temperature (T-T)
-20 - 60 °C
- 3D
yes
- Package weight
1.22 kg
- HDMI in
1
- Number of HDMI outputs
1
- Maximum transfer distance
40 m
- Remote (IR) output
1
- RJ-45 output ports
1
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3628749 ATEN VE1833 HDMI extender HDMI 3840 x 2160 Pixel
Description
Revolutionize your AV installation with the ATEN VE1833, a state-of-the-art HDBaseT 3.0 Lite transceiver that seamlessly adapts to any requirement. This compact device offers the unique ability to function as a transmitter or as a receiver with a simple changeover, WAS simplifies the storage and maximizes the flexibility on the spot. The VE1833 transmits uncompressed true 4K video, audio, USB 2.0 and zero latency control signals up to 40 meters using a single CAT 6a cable. The bi-directional PoH and professional audio features make it the ideal all-in-one solution for conference rooms, lecture theaters and museums that do not want to make compromises in terms of quality and installation effort.
