Bachmann 924084 Pull-cord switch
EAN:
Part number:
Item no:
Technical specifications
- Dimmer type
- Material: Plastic
- Colour: white
- Transparent: No.
- Design of surface: Matt
- Nominal voltage: 250 V
- Nominal current: 16 A
- Halogen-free: No.
- Material quality: Thermoplastic
- RAL number (similar): 9010
- Operating mode: Rocker
- Product type
Pull-cord switch
- Operating voltage
250 V AC
- Similar RAL
9010
- Dim
(L x W x H) 54.5 x 24.5 x 15.5 mm
- Length
54.5 mm
- Width
24.5 mm
- Height
15.5 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3549642 Bachmann 924084 Pull-cord switch
Description
Cord intermediate switch series 8075
Colour casing/rocker: White/white
2 A, 250 Vac, 1-pole, off switch,
Housing and strain relief screwed
Connection terminal for the neutral conductor,
Screw contacts,
For double insulated flat cables 2 x 0.75 mm²
Dimensions: LBH 54.5 x 24.5 x 15.5 mm
Packed in polybag.
This text is machine translated.
Colour casing/rocker: White/white
2 A, 250 Vac, 1-pole, off switch,
Housing and strain relief screwed
Connection terminal for the neutral conductor,
Screw contacts,
For double insulated flat cables 2 x 0.75 mm²
Dimensions: LBH 54.5 x 24.5 x 15.5 mm
Packed in polybag.
This text is machine translated.
