Bachmann 924354 LED pull-cord dimmer switch Suitable for light bulbs: LED bulb
EAN:
Part number:
Item no:
Technical specifications
- Dimmer type
- Material: Plastic
- Colour, black
- Transparent: No.
- Design of surface: Matt
- Nominal voltage: 230 V
- Halogen-free: No.
- Material quality: Thermoplastic
- RAL number (similar): 9005
- Button mode
- Power 5..100 W
- Product type
LED pull-cord dimmer switch
- Operating voltage
230 V
- Power rating (min.)
5 W
- Power rating (max.)
100 W
- Suitable for light bulbs
LED bulb
- Switching capacity (LED)
35 W
- Similar RAL
9005
- Dim
(L x W x H) 81 x 32 x 23 mm
- Length
81 mm
- Width
32 mm
- Height
23 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3550174 Bachmann 924354 LED pull-cord dimmer switch Suitable for light bulbs: LED bulb
Description
LED-cord pushbutton dimmer
Series 8119
With soft start and memory function
Electronic, transistor-controlled
Phase section dimmer without choke coil
230 V ~ (+/- 10 %), 50 Hz,
5-100 W/VA, LED 3-35 W,
L/W/H 81 mm x 32 mm x 23 mm
This text is machine translated.
Series 8119
With soft start and memory function
Electronic, transistor-controlled
Phase section dimmer without choke coil
230 V ~ (+/- 10 %), 50 Hz,
5-100 W/VA, LED 3-35 W,
L/W/H 81 mm x 32 mm x 23 mm
