BALLUFF BAM009R Plunger probe BAM009R 1 pc(s)
Product type
Plunger probe
Type
BAM009R
Content
1 pc(s)
Length
20.00 mm
Width
12 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Balluff BAM009R Plummer Sample Solutions
- Dimensions 28 x 12 x 20 mm
- Mounting: Clamps
- Application: For inductive sensors Ø8
- For inductive BES M8 sensors
- Material: Aluminium anodized, red
- Short description: Fixed stop
Technical specifications
- Main features:Dimension 28 x 12 x 20 mm
- Mounting: Clamps
- Short description: Fixed stop
- Material: Aluminium anodized, red
- Ambient temperature: -25 to 100 °C
- Application: For inductive sensors Ø8
- For inductive BES M8 sensors
- Additional features:
- Delivery scope: Stop sleeve|clamp block|screw ISO 4762-M3x8 (2x)
- Application: For inductive sensors Ø8|for inductive sensors BES M8
- Material: Aluminium
- Dimensions 28 x 12 x 20 mm
- Mounting: Clamps
- Tightening torque 1.5 Nm
- Ambient temperature: -25 to 100 °C
- Tightening torque max. 1.5 Nm
- Surface protection: Anodized, red
- Clamp system: Screws
- Short description: Fixed stop
- Product type
Plunger probe
- Type
BAM009R
- Content
1 pc(s)
- Length
20.00 mm
- Width
12 mm
- Height
20 mm
- Material
Aluminium
- Max. temperature
100 °C
- Min. temperature
-25 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3418234 BALLUFF BAM009R Plunger probe BAM009R 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3418234 BALLUFF BAM009R Plunger probe BAM009R 1 pc(s)
Description
Our compact Pluger Probe offers rugged design for harsh applications. It is suitable for Ideal for welding devices and punching applications as well as for applications with controlled workpiece ejection. The complete set includes sensor, housing and springs. You can choose between different types of plunger and three spring voltages: The two-piece housing simplifies maintenance. Short description=fixed stop, use=for inductive sensors Ø8für BES M8 inductive sensors, material=aluminum anodized, red, dimension=28 x 12 x 20 mm, mounting=clamps, ambient temperature=-25...100 °C
