BALLUFF BAM00HW Terminal block BAM00HW 1 pc(s)
Product type
Terminal block
Type
BAM00HW
Content
1 pc(s)
Length
34.00 mm
Width
56.00 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Balluff BAM00HW Universal mounts
- Dimensions 56 x 34 x 34 mm
- Mounting: Screws, clamps
- Use: For sensors Ø30 mm
- For M30 sensors
- Design: Terminal block with fixed stop
- Material: Anodised aluminum
Technical specifications
- Main features:Dimension 56 x 34 x 34 mm
- Design: Terminal block with fixed stop
- Mounting: Screws, clamps
- Material: Anodised aluminum
- Use: For sensors Ø30 mm
- For M30 sensors
- Additional features:
- Design: Terminal block with fixed stop
- Functional principle: Clamp holder
- Delivery: Clamp holder (1x)|Screw EN ISO 4762-M6x25
- Use: For sensors Ø30 mm|for sensors M30
- Product type
Terminal block
- Type
BAM00HW
- Content
1 pc(s)
- Length
34.00 mm
- Width
56.00 mm
- Height
34.00 mm
- Material
Aluminium
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3418276 BALLUFF BAM00HW Terminal block BAM00HW 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3418276 BALLUFF BAM00HW Terminal block BAM00HW 1 pc(s)
Description
Our mounting clamps, clamping blocks and retaining brackets offer positioning and fixing in one. They are characterized by simple installation and rugged design. They can choose between different sizes for sensor diameters from 3 mm to 36 mm, also for cubic designs, and versions such as aluminum, stainless steel and plastic. Our sensor holders can be combined with the mounting system BMS. The high-quality sensor holders are designed and tested for Balluff sensors. They are characterized by precision and durability. Version = clamp block with fixed stop, use = for sensors Ø30 mmfor M30 sensors, material = aluminum anodized, dimensions = 56 x 34 x 34 mm, fixing = screws, clamps
