Image similar
BALLUFF BIS0176 RFID-Tag BIS M-127-02/A 1 pc(s)
Product type
RFID-Tag
Type
BIS M-127-02/A
IP rating
IP67
Content
1 pc(s)
Length
93 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Balluff BIS0176 Square tags for the RF range (13.56 MHz)
- Dimensions 93 x 43.3 x 57.2 mm
- Product group: HF (13.56 MHz)
- Antenna shape: Round
- UID serial number, read-only: 8 bytes
- Memory type: FRAM
Technical specifications
- Main features:Dimension 93 x 43.3 x 57.2 mm
- Antenna shape: Round
- Installation: Metal-free (free zone)
- On metal
- Shielded in metal
- PA 12 case material
- Diecast aluminium
- Storage temperature: -25...85 °C
- User data, read/write: 2000 bytes
- Product group: HF (13.56 MHz)
- Protection class IP67
- Memory type: FRAM
- UID serial number, read-only: 8 bytes
- Ambient temperature: -25 to 70 °C
- Supported media types: DIN ISO 15693
- Additional features:
- Functional principle: Data carrier
- Dimensions 93 x 43.3 x 57.2 mm
- Mounting: Metal-free (free zone)|on metal|flush in metal
- Housing material: PA 12|Aluminium die-cast
- EN 60068-2-27, Shock: Yes
- EN 60068-2-6, Vibration: Yes
- Protection class IP67
- Ambient temperature: -25 to 70 °C
- Application weight 180 g
- Antenna shape: Round
- Constant shock load: Yes
- EN 60068-2-32, Free Case: Yes
- Storage temperature: -25...85 °C
- Reading time: For 16 bytes: 0.03 s|User ID for 8 bytes: 0.02 s.
- Read cycles: Unlimited
- Programming time: For 16 bytes: 0.060s
- Programming cycles: ≥ 10,000,000,000
- Memory organization: 250 × 8 bytes
- User data, read/write: 2000 bytes
- Memory type: FRAM
- EN 55022: Gr. 1, Cl. B
- Data retention time/years: ≥ 10 at 55 °C.
- UID serial number, read-only: 8 bytes
- Supported media types: DIN ISO 15693
- Product type
RFID-Tag
- Type
BIS M-127-02/A
IP67
- Content
1 pc(s)
- Length
93 mm
- Width
43.3 mm
- Height
57.2 mm
- Enclosure material
PA12
Aluminium (die-cast)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3418788 BALLUFF BIS0176 RFID-Tag BIS M-127-02/A 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3418788 BALLUFF BIS0176 RFID-Tag BIS M-127-02/A 1 pc(s)
Description
BIS M uses the high frequency (HF) 13.56 MHz and supports the standard either in accordance with DIN ISO 15693 and/or DIN ISO 14443. Due to the large variety of passive data carriers in dimensions, design, memory size, working temperature, material, Antenna technology, installation, range you can implement almost any technical task with application optimized. BIS M is the robust system with absolute data security. Product group=HF (13.56 MHz), dimension=93 x 43.3 x 57.2 mm, UID serial number, read only=8 bytes, user data, read/write=2000 bytes, Storage type=FRAM, supported data carrier types=DIN ISO 15693, antenna shape=round, installation=metal free (free zone) on metal flush in metal, storage temperature=-25...85 °C, ambient temperature=-25...70 °C, casing material=PA 12 Aluminium die-cast, protection class=IP67, approval/conformity=CEWEEE
