Name: BALLUFF BOH000F BOH000F Optical sensor head 1 pc(s) (L x W x H) 8.00 x 5.00 x 8.00 mm
Brand: BALLUFF
SKU: 3416276

Shown is a three-pole round connector with two metal nuts and a short cable.

Image similar

Product type

Optical sensor head

Connector

Plug

Socket

Type

BOH000F

Cable length

1 m

Enclosure material

Stainless steel

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Balluff BOH000F One way light barriers in different light types

Dimensions 8.8 x 8 x 8 mm
Series M5
Interface: For switching amplifier
Optical sensor head
Optical functional principle: One-way light barrier

Technical specifications

Main features:Dimension 8.8 x 8 x 8 mm
Active surface, material: Glass
Connection: Cable with connector, M8x1 socket, 1 m, PUR
Series M5
Attachment: Nut M5x0.5
Optical sensor head
Optical functional principle: One-way light barrier
Housing material: Stainless steel
Smallest part type: 0.40 mm
Light: MICROSPOT-LED red light
Light spot size: Ø 10 mm with 100 mm
Range 0 - 2 m
Interface: For switching amplifier
Beam characteristics: Varied, max. 2.5°
Additional features:
Optical sensor head
Connection: Cable with connector, M8x1-|female, 1 m, PUR
Rated switching distance Sn: 2000 mm
Cable diameter D 1.80 mm
Cable length 1 m
Range 0 - 2 m
Series M5
Shape: Cylinder|Straight optics|Connection 90°
Reference basic device: BAE SA-OH-059-…

Product type: Optical sensor head

Type: BOH000F

Connector: Plug
Socket

Cable length: 1 m

Enclosure material: Stainless steel

: 2 m

: IP65

Min. temperature: -10 °C

Max. temperature: 55 °C

Length: 8.00 mm

Width: 5.00 mm

Height: 8.00 mm

Dim: (L x W x H) 8.00 x 5.00 x 8.00 mm

Content: 1 pc(s)

Switching distance (max.): 2000 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3416276 BALLUFF BOH000F BOH000F Optical sensor head 1 pc(s) (L x W x H) 8.00 x 5.00 x 8.00 mm

User & Safety Instructions

User & Safety Instructions 3416276 BALLUFF BOH000F BOH000F Optical sensor head 1 pc(s) (L x W x H) 8.00 x 5.00 x 8.00 mm

Description

The Microremote sensors' modular system with innovative sensor elements meets your individual requirements: Various housing designs ensure a particularly high degree of design freedom, precise optoelectronic components ensure a high level of process accuracy in every application. Series=M5, dimension=8.8 x 8 x 8 mm, interface=for switching amplifier, operational principle=optical sensor head, operational principle optical=one-way light barrier, beam characteristic=diverse, max. 2.5°, light type=MICROSPOT-LED red light, light spot size=Ø 8 mm at 100 mm, range=0...2 m, connection=cable with connector, M8x1 plug, 1.00 m, PUR, housing material=brass, active surface, material=glass, approval/conformity=CEWEEE

This text is machine translated.
