Barthelme 66000759 DMX controller 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Height: 23 mm
- Width 50 mm
- Design: Static
- Protection class (IP) IP20
- Suitable for outside use: No.
- Length: 153 mm
- Power output: 180 W
- Constant luminous flux regulation: Yes
- Dimmer 0-10 V: No
- Dimmer 1-10 V: No
- DALI dimming: No.
- DMX dimming: Yes
- Dimmer DSI: No.
- Dimmer potentiometer (built-in): No.
- Dimming LineSwitch: No.
- Dimmer manufacturer-specific: No.
- Mains voltage modulation dimming: No.
- Dimming Phase section: No.
- Dimming leading edge: No.
- Dimming programmable: Yes
- Dim. RF: No.
- Dimming Sine Wave Reduction: No.
- Dimming Touch and Dim: No.
- Zigbee dimming: No.
- Dimming with push-button: No.
- Without dimmer function: No.
- Output current: 2000 mA
- Output voltage 12 - .24 V
- Housing: Plastic housing
- Suitable for constant voltage: Yes
- Suitable for DC voltage (primary side): Yes
- Product type
DMX controller
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3550244 Barthelme 66000759 DMX controller 1 pc(s)
Description
DMX standard for controlling LED systems, completely networked with DMX-compatible devices, stand-alone operation possible, four controllable channels from monochrome to RGBW, input voltage: 12 to 28 VDC, com+ common anode, compact housing design, high PWM frequency of 2.5 kHz (flicker-free)
