BC.Schaltakt.Adapter Blue-Control 1-channel Actuator Switching capacity (max.) 3600 W Blue
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 114.99 / piece)
€ 114.99
incl. VAT
14-day return policy included
Highlights & Details
BlueControl adapter with earthing contact socket and increased contact protection; ON/OFF function; manual operation possible
- Adapter plug/adapter with earthing contact socket-outletWith Bluetooth mesh technologyON/OFF functionManual operation possible
Technical specifications
- Transmition power < 10 mWRange (free field) up to 40 m (mesh topology)Integrated antennaNumber of station memory 1024Switch contact 1x normally open contact (relay contact, not potential-free)Switchable voltages 230 V ACLoad current 16 AResistive load 3,600 W.Bulbs 1,000 W.Fluorescent lamps (series compensated) 1,500 W.Fluorescent lamps (parallel compensated) 130 W.Low-voltage halogen lamps with conventional transformer 1,000 W.Low-voltage halogen lamps with electronic transformer 1,000 W.High-voltage halogen lamps 1000 W.Energy-saving lamps 100 WLEDs (*Note manufacturer's specifications for power specifications depending on the associated ballasts) 150 W.Standby power (PV) < 0.5 W.Weight 136 gr.Standard operating temperature 25 °C.Operating temperature: -20 to + 60 °C.Storage temperature -30 °C to +80 °CPlug the installation into the socketCompliance RED
- Product type
Actuator
- Series
Blue-Control
- Dim
(W x H x D) 78 x 105 x 82 mm
- Transfer Standard (Smart Home)
Bluetooth Low Energy
- Max. switching capacity
3600 W
- Used at
Indoors
Mains socket
IP20
- Power supply (LOV)
mains-powered
- Operating voltage
230 V
- Data transfer (Smart Home)
Wireless
- Channels
1
- Frequency
2.4 GHz
40 m
- Mounting type
Push-fit
- Factory colour
Blue
- Suitable for
Busch-Jaeger
- Width
78 mm
- Height
105 mm
- Depth
82 mm
- Hub
Not required, optional for remote access
- Data exchange
Bidirectional (bi)
n.rel.
- Weight
136
Documents & Downloads
Datasheet
Datasheet 2594638 BC.Schaltakt.Adapter Blue-Control 1-channel Actuator Switching capacity (max.) 3600 W Blue
User & Safety Instructions
User & Safety Instructions 2594638 BC.Schaltakt.Adapter Blue-Control 1-channel Actuator Switching capacity (max.) 3600 W Blue
Description
BlueControl adapter plug/adapter with earthing contact socket and increased touch protection; ON/OFF function; manual operation possible; BT inside, 230 V~, 50 Hz, 3,600 W, 2.4 GHz, IP20
This text is machine translated.
This text is machine translated.
Features
- With increased touch protection
Hints
Free Control 3.0 products are not directly compatible with other Free Control products. Connection requires using the gateway.
