Name: Berger & Schröter Winch 31807 Traction (rolling)=11.8 kg Cordless remote control, incl. window, Corded remote control
Brand: Berger & Schröter
SKU: 1667579

Electric winch with a pulling force of 13,000 pounds, equipped with a steel cable, a hook, a remote control, and a cable.

Unavailable

2 Piece(s)

Show alternatives

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Rope winch 12 V 5900/11800 kg Steel rope

Steel cable 26 m
11800 kg
wireless control system;

Technical specifications

1.7 m battery connection cable, 3.5 m cable remote control, power consumption 400A

Product type: Winch

Fastening method: Fixed mount

Operating voltage: 12 V

Weight: 38.5 kg

Width: 55.2 cm

Height: 21.5 cm

Depth: 16 cm

Cable speed (with load): 1.75-4.7 m/min

Cable speed (without load): 10 m/min

Rope length: 26 m

Rope diameter: 9.5 mm

Features: Cordless remote control
incl. window
Corded remote control

Transmission ratio: 265:1

Traction (rolling): 11.8 kg

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1667579 Berger & Schröter Winch 31807 Traction (rolling)=11.8 kg Cordless remote control, incl. window, Corded remote control

Description

12 V rope winch including roller window, loads up to 11800 kg can be easily moved or pulled with a pulley (not included in the delivery). Incl. 26 m long and 9.5 mm thick wire rope and load hook, operation via 3.5 m cable remote control, and wireless remote control approx. 1.7 m long battery connection cable, incl. Relay box, gear ratio of 265:1, dimensions approx. 552 x 160 x 215 mm, weight 39 kg, rope speed from 1.75 to 4.7 m/minute, (without last 10 m/minute). Chrome/black color, current consumption up to 400 A. With detailed assembly instructions.

This text is machine translated.
