BJZ Alfaplan S ESD bench mat Grey (L x W) 1200 mm x 600 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
ESD table mat, platinum gray, 600 x 1200 mm
- Two-layered synthetic rubber;
- PVC, silicone and halogen-free
- Flame-resistant (e.g. to solder spray)
- Slightly structured surface for reflection reduction
- Two-layered covering structure
Technical specifications
- Hardness: 75
- Chemical resistance: Resistant to commercial cleaners (water-based, without oil/wax)
- Product type
ESD bench mat
- Type
Alfaplan S
- Factory colour
Grey
- Connection
10.3 mm stud and socket
- Material
Synthetic rubber
- Surface resistance
10⁹ Ω
- Leak resistance
10⁸ Ω
- Length
1200 mm
- Width
600 mm
- Dim
(L x W) 1200 mm x 600 mm
- Range of use
ESD
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3846387 BJZ Alfaplan S ESD bench mat Grey (L x W) 1200 mm x 600 mm
User & Safety Instructions
User & Safety Instructions 3846387 BJZ Alfaplan S ESD bench mat Grey (L x W) 1200 mm x 600 mm
Description
High-quality ESD table mat made of two-layer synthetic rubber for reliable diversion of electrostatic charges at the work place.
This text is machine translated.
This text is machine translated.
Features
- Two push button connections 10.3 mm
- Thickness: 2 mm
Scope of delivery
- 1x ESD bench mat
