Blickle 867660 BH-DSPKGSPO 125K Sheet metal fixed wheel Wheel diameter: 125 mm Load capacity (max.): 700 kg 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Load capacity at 4 km/h: 700 kg
- Wheel body material: High-quality cast polyamide
- Material run lining: Plastic
- Colour: Carpet, natural-beige
- Colour wheel body: Natural beige
- Temperature resistance up to 80 °C
- Temperature resistance min -20 oC
- Coating hardness 80 shore D.
- Without a trace: Yes
- Anti-static: No.
- Stainless steel: No.
- Heat resistant: No.
- Autoclave-compatible: No.
- Resistant to hydrolysis: No.
- Mounting type: Screw-on plate
- Associated wheel: DSPKGSPO 125K
- Product type
Sheet metal fixed wheel
- Wheel Ø
125 mm
- Load capacity (max.)
700 kg
- Total height
170 mm
- Size
140 x 110 mm
- Wheel width
50 mm
- Bearing type
Ball bearing
- Material
Plastic
- Factory colour
Ecru beige
- Content
1 pc(s)
- Weight
1.908 kg
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3050263 Blickle 867660 BH-DSPKGSPO 125K Sheet metal fixed wheel Wheel diameter: 125 mm Load capacity (max.): 700 kg 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3050263 Blickle 867660 BH-DSPKGSPO 125K Sheet metal fixed wheel Wheel diameter: 125 mm Load capacity (max.): 700 kg 1 pc(s)
Description
Steel sheet-Bockrolle, heavy-duty design, with mounting plate,
Double steering wheel made of cast polyamide
Housing: Series BH
• Sheet steel, galvanized, blue passivated, Cr6-free
• Heavy fork and floor plate
Wheel: Series DSPKGSPO
• High quality cast polyamide, unbreakable, hardness 80 shore D, color natural beige
Other properties:
• High chemical resistance to many aggressive media
• Temperature resistance: -20 °C to +80 ° C, reduced load capacity at over +35 °C.
• For pressure-sensitive floors, observe surface pressure
• Wheels with a wide contact surface which allow for use outside the slide rails
This text is machine translated.
Double steering wheel made of cast polyamide
Housing: Series BH
• Sheet steel, galvanized, blue passivated, Cr6-free
• Heavy fork and floor plate
Wheel: Series DSPKGSPO
• High quality cast polyamide, unbreakable, hardness 80 shore D, color natural beige
Other properties:
• High chemical resistance to many aggressive media
• Temperature resistance: -20 °C to +80 ° C, reduced load capacity at over +35 °C.
• For pressure-sensitive floors, observe surface pressure
• Wheels with a wide contact surface which allow for use outside the slide rails
This text is machine translated.
