Blickle 937373 LPFE-ALTH 101K-AS-FA-CO Heavy-duty swivel wheel Wheel diameter: 100 mm Load capacity (max.): 350 kg 1 pc(
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Load capacity at 4 km/h: 350 kg
- Material wheel body: Aluminum die casting
- Material: Polyurethane lining
- Colour run lining: Grey
- Colour wheel body: Silver gray
- Temperature resistance up to 70 °C
- Temperature resistance min -20 oC
- Coating hardness 92 Shore A
- Without a trace: Yes
- Anti-static: Yes
- Stainless steel: No.
- Heat resistant: No.
- Autoclave-compatible: No.
- Resistant to hydrolysis: No.
- Mounting type: Screw-on plate
- Associated wheel: ALTH 101/15K-AS-CO
- RELATED FIXED ROLLER: BPFE-ALTH 101K-AS-FA-CO.
- Product type
Heavy-duty swivel wheel
- Wheel Ø
100 mm
- Load capacity (max.)
350 kg
- Total height
170 mm
- Size
100 x 85 mm
- Wheel width
40 mm
- Bearing type
Ball bearing
- Material
Polyurethane
- Factory colour
Grey
- Content
1 pc(s)
- Weight
3.453 kg
Documents & Downloads
Datasheet
Datasheet 3056422 Blickle 937373 LPFE-ALTH 101K-AS-FA-CO Heavy-duty swivel wheel Wheel diameter: 100 mm Load capacity (max.): 350 kg 1 pc(
User & Safety Instructions
User & Safety Instructions 3056422 Blickle 937373 LPFE-ALTH 101K-AS-FA-CO Heavy-duty swivel wheel Wheel diameter: 100 mm Load capacity (max.): 350 kg 1 pc(
Description
Heavy-duty swivel castor with polyurethane rotating springs,
Heavy-duty wheel with polyurethane tread Blickle Extrathane®, with aluminum wheel body, with strongly balmy running surface, with thread protection made of steel, anti-static
Housing: Series LPFE
• Solid steel welding construction, solid forged part, galvanically galvanized, yellow passivated, Cr6-free
• Outstanding spring damping properties thanks to patented disc spring construction
• One or two sealed lifetime lubricated deep groove ball bearings in rotating assembly starting from wheel-Ø 125x50 mm
Wheel: Series ALTH
• Coating: High-quality polyurethane elastomer Blickle Extrathane®, hardness 92 shore A, color gray, trackless, contact-free
• Wheel body: Die-cast aluminum, silver-gray color
Other properties:
• High chemical resistance to many aggressive media
• Temperature resistance: -20 °C to +70 ° C, short term to +90 °C, reduced load capacity above +40 °C.
• Electrical leakage (ohmic resistance) ≤ 107 Ω
• With heavy wheel body, center stage design
This text is machine translated.
Heavy-duty wheel with polyurethane tread Blickle Extrathane®, with aluminum wheel body, with strongly balmy running surface, with thread protection made of steel, anti-static
Housing: Series LPFE
• Solid steel welding construction, solid forged part, galvanically galvanized, yellow passivated, Cr6-free
• Outstanding spring damping properties thanks to patented disc spring construction
• One or two sealed lifetime lubricated deep groove ball bearings in rotating assembly starting from wheel-Ø 125x50 mm
Wheel: Series ALTH
• Coating: High-quality polyurethane elastomer Blickle Extrathane®, hardness 92 shore A, color gray, trackless, contact-free
• Wheel body: Die-cast aluminum, silver-gray color
Other properties:
• High chemical resistance to many aggressive media
• Temperature resistance: -20 °C to +70 ° C, short term to +90 °C, reduced load capacity above +40 °C.
• Electrical leakage (ohmic resistance) ≤ 107 Ω
• With heavy wheel body, center stage design
This text is machine translated.
