Power transformer VCM 25/2/9
- to N/A
- Excellent size to power ratio
- Vacuum resin moulded (self extinguishing to UL 94 V-0)
- Mounting tabs on side of housing
Technical specifications
- Product type
PCB mount transformer
- Output voltage
9 V AC
- Output voltage (number x voltage)
2 x 9 V AC
- No. of inputs
1 x
- No. of outputs
2 x
- Input voltage
230 V AC
- Input voltage (number x voltage)
1 x 230 V AC
25 VA
- Width
81.20 mm
- Height
49.2 mm
- Length
55 mm
- Type
VCM 25/2/9
- Dim
(L x W x H) 55 x 81.20 x 49.2 mm
- Connection
Solder pins
- Frequency
50 - 60 Hz
- Weight
610 g
- Content
1 pc(s)
- Insulation class
VDE=B, UL=105
- Test voltage
500 V
- Test mark
C-UL-US, ENEC 10 (VDE)
- Max. ambient temperature
+40 °C
- Mounting type
Screw fastening
- Efficiency
82 %
Documents & Downloads
Datasheet
Datasheet 2206936 BLOCK VCM 25/2/9 PCB mount transformer 1 x 230 V AC 2 x 9 V AC 25 VA
User & Safety Instructions
User & Safety Instructions 2206936 BLOCK VCM 25/2/9 PCB mount transformer 1 x 230 V AC 2 x 9 V AC 25 VA
Description
Safety isolating transformer to IEC 61558-2-6, DIN EN 61558-2-6, VDE 0570 part 2-6. Power transformer to IEC 61558-2-1, DIN EN 61558-2-1, VDE 0570 part 2-1 (without VDE-Approval)
Features
- Minimum size with high power; also with double output voltage for series or parallel connection; permanent corrosion protection, high insulation value and highest electrical reliability by casting resin compound XtraDenseFill
Hints
For more technical data on BLOCK's VCM 25/2/9 PCB transformer, please see its datasheet under 'downloadable documents'.
