Bosch Accessories 2608642106 2608642130 Scoring saw blade 120 x 22 x 3.6 mm Number of cogs: 12 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Scoring blade Top Precision Best for Laminated Panel, 120 x 22 x 2.8 - 3.6 mm
- Maximum precision & durability: Equipped with extra hard Microteq teeth made from home-made carbide for first-class cut quality in coated plates.
- Clean edges without cracks: Two-part, adjustable vorritz saw blade (conical / conical) effectively prevents the coating from tearing out on the underside of the material.
- Protection against corrosion & friction: The special Cleanteq coating reduces the adhesion of resin and adhesives and protects the blade against overheating.
- Low noise and vibration: Specially laser-cut strain relief slots provide a high smoothness and clear noise reduction during sawing.
Technical specifications
- Cutting width 2.8
- Product type
Scoring saw blade
- Content
1 pc(s)
- (Ø)
120 mm
- Bore Ø
22 mm
- Thickness
3.6 mm
- Circular saw blade size
120 x 22 x 3.6 mm
- Material
Carbide metal
- Material suitability
Laminate
- Number of cogs
12
- Tooth form
ATB
- Rotational speed (max.)
15900 U/min
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3804125 Bosch Accessories 2608642106 2608642130 Scoring saw blade 120 x 22 x 3.6 mm Number of cogs: 12 1 pc(s)
Description
The Top Precision Best for Laminated Panel scoring saw blade enables industrial-quality precision for very demanding applications in laminated panels that are coated on one or two sides. This high performance and quality is reinforced by the unique extra-hard Microteq teeth produced internally at Bosch and made from robust carbide grain. Cleanteq also reduces the adhesion of residues, such as resin and adhesive, to ensure particularly clean results while preventing corrosion and keeping the blade cool. The adjustable scoring saw blade is designed for cutting chipboard, panel materials and veneered laminate. The blade is compatible with horizontal and vertical panel saws. The Top Precision Best for Laminated Panel scoring saw blade has ATB (alternating tooth) geometry, allowing clean cuts in all types of wood and laminated panels. External diameter mm: 120, hole mm: 22, cut width (b1) mm: 2.8, sheet thickness (b2) mm: 3.6, cut width (b1) mm / sheet thickness (b2) mm: 2.8/3.6, number of teeth: 12+12, tooth shape: ES, Max. Rotation speed (rpm): 15900, Cutting result: 4, Clamping angle ° w1: 11, Clearance angle ° w2: 17
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1x two-piece pre-pinion circular saw blade Top Precision Best for Laminated Panel (120 x 22 x 2.8 - 3.6 mm)
