CasaFan CLASSIC OUTDOOR 132 BZ-PR Flügel Kunststoff Palme/Rattan braun Ceiling fan 61 W (Ø x H) 132 cm x 375 mm Bronze W
EAN:
Part number:
Item no:
Highlights & Details
CasaFan CLASSIC OUTDOOR 132 BZ-PR wing plastic palm/rattan Brown
- ´- Ideal for covered porches, balconies or terraces.
- - Weather-proof ceiling fan with IP44 - suitable for use in protected outdoor areas.
- - Control via pull switch with 3 speed levels and forward and reverse operation.
- - Including 150 mm overhead bar - mounting on slopes with auxiliary construction possible
Technical specifications
- For rooms up to 25m²
- Product type
Ceiling fan
- Operating voltage
230 V
- Switching stages
3
- (Ø)
132 cm
61 W
- Air flow rate
7.852 m³/h
- Rotational speed
176 U/min
- Noise emission
27.6 dBa
- Grid diameter
132 cm
- Wing colour
Brown
Rattan white
- Case colour
Bronze
- Fan features
Winter-proof
- Dim
(Ø x H) 132 cm x 375 mm
- Weight
8479 g
n.rel.
- Rotor blades
5
- Reversible rotation direction
Yes
- Rotational speed (max.)
176 U/min
- Speed levels
3
- Max. power consumption
61 W
- Air discharge
7852 m³/h
- Material
Steel
Plastic
- Height
375 mm
- Length
1320 mm
- Depth
1320 mm
- Service value
2.1 (m³/min)/W
- Power supply (LOV)
mains-powered
- Height-adjustable
No
- Width
1320 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3450934 CasaFan CLASSIC OUTDOOR 132 BZ-PR Flügel Kunststoff Palme/Rattan braun Ceiling fan 61 W (Ø x H) 132 cm x 375 mm Bronze W
Description
The CasaFan classic outdoor ceiling fan lends a tropical flair to protected outdoor areas such as verandas or covered terraces and is optimally protected against weather thanks to protection class IP44. Depending on the model, wings in palm or rattan look are available for an exotic ambience or smooth variants in white or bronze for a classic look. All models are made of weather-resistant plastic and ensure pleasant air circulation. Three speed levels as well as forward and reverse operation can be controlled comfortably via pull switch.
This text is machine translated.
This text is machine translated.
Scope of delivery
- - Ceiling fan
- - Pull switch
- - Mounting hardware
- - Installation and operating instructions
