Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Chauvin Arnoux insulation measuring and multimeter set
- MH 401 Insulation measuring device
- Measurement of the insulation at 250 / 500 / 1000 V DC up to 2000 Ω
- Measurement of continuity resistance with currents from 200 mA
- Operating comfort with the functions: Timer / data hold / test lead compensation
- Security CAT III 300 V (IEC 61010-1)
- CA 5231 Multimeter (TRMS)
- TRMS AC digital multimeter with compact and shock-proof housing with foldable stand
- AC/DC currents up to 600 A with clip-on current transformer
- AC/DC-voltages up to 1000 V - High sensitivity and resolution up to 0.01 mV
- VLowZ measuring function to avoid measurement errors due to stray voltages
- Overload protected up to 8000 V
- BASIC FUNCTIONS V AC, V DC, A AC, A DC, RESISTANCE, Acoustic Continuity check, diode test
- Additional functions: Non-contact voltage detection, display memory (HOLD)
- LM 76 Luxmeter
- Removable probe
- Easy to Use
- Compact
- Compensation of the spectral error
- High accuracy over a large measuring span
- MAX, HOLD
- Selection of the measuring unit
- RPM 82 digital tachometer
- Digital tachometer with or without contact
- Accuracy 0.05 % + 1 digit
- Automatic selection of measuring ranges
- MAX, MIN, HOLD FUNCTION
- Speed and throughput speed:
- Speed with contact: 0.5 min-1 to 19,999 min-1
- Speed without contact 2.5 min-1 to 99,999 min-1
- Throughput speed: 0.05 m/min to 1999.9 m/min.
- CM 625 multiple soldering pliers
- Display 4300 digit
- Current up to 400 A AC/DC TRMS
- VOLTAGE 600 V AC/DC TRMS
- Ø Encapsulation diameter 30 mm
- HOLD function
- VT 35 socket and FI tester
- Tester for sockets and FI-circuit breaker (10 mA and 30 mA)
- Testing of FI-protective switches from 10 to 35 mA
- Check for: No phase, no earth, no neutral wire
- Test of phase/neutral conductor interchange and phase/earth
- Simple and fast connection via earthing contact socket
- FIT-100 FI/RCD TESTER
- Errors are indicated by changing the background illumination
- Precise RCCB testing
- 3-digit measured value display
- Checks and measures the trip values of RRDS
- Selection of 0° or 180° phase angle
- Safety EN 61010-1 CAT III 600 V
Technical specifications
- Insulation resistance (max.) 2000 Ω
- CA 762 Voltage tester
- Voltage testing
- Voltages:
- 12 V ≤ U ≤ 690 VAC
- 12 V ≤ U ≤ 750 VDC
- Frequencies: DC, 16 2/3 Hz to 800 Hz
- 400 kΩ input impedance
- Max. Peak current 3.5 mARMS
- Polarity indicator: Yes
- Display of dangerous voltages:
- The red LED (extra low voltage) lights up as soon as the voltage is transmitted via a non-hazardous extra-low voltage
- And blinks the faster the higher the connected voltage
- Display of external conductor / neutral conductor:
- At more than 50 V (45 - 65 Hz)
- At more than 150 V (16 2/3 Hz - 45 Hz)
- Acoustic continuity test
- Response threshold: 100 Ω typical (150 Ω max.)
- Extended continuity test: 2 kΩ, 60 kΩ, 300 kΩ
- Test current: ≤ 1 mA
- Open circuit voltage ≤ 3.3 V
- Protection: Up to 1000 V.
- Rotating field direction display: 2-wire method
- VOLTAGE L-L 50 V ≤ U ≤ 690 VAC
- Frequency: Between 45 Hz and 400 Hz
- Acoustic signal: Interrupted sound when voltage is detected, continuous tone when continuity test is performed
- Standards and electrical safety:
- IEC 61010 600 V CAT IV.
- IEC 61243-3 for voltage tester
- IEC 61326-1, Emissions and Immunity in Industrial Environments
- Enclosure rating:
- Housing IP65
- Test probes (depending on option and item no.): IP2X
- Climate conditions Use from -15 °C to +45 °C / 20% to 95% relative. Humidity
- Power supply 2 batteries 1.5 V (AAA or LR3)
- Battery life: 7 000 measurements each of 10 sec.
- Product type
Insulation tester
- Test voltage
250 V
500 V
1000 V
- Reading type
Insulation resistance
- Continuity testing
2000 Ω
Manufacturer's standards (no certificate)
- Dim
(L x W x H) 55 x 205 x 90 mm
- Weight
600 g
- Display type
Digital (LCD)
- Voltage reading range (max.)
600 V
- Voltage reading range (min.)
0 V
- Reading category
CAT III 600 V
- Width
205 mm
- Height
90 mm
- Length
55 mm
Documents & Downloads
Datasheet
Datasheet 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
Datasheet 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
Datasheet 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
User & Safety Instructions 3410107 Chauvin Arnoux KIT - CONTRÔLE CE Insulation tester 250 V, 500 V, 1000 V
Description
MH 401 Insulation measuring device
The Mh 401 multimeter is a simple insulation measuring device, which enables the insulation measurement at 250, 500 or 1000 V for resistances up to 2000 Ω.
The meter also enables the measurement of AC voltages up to 600 V AC and continuity tests.
It includes automatic test lead compensation, warns of the presence of voltage and offers the following additional functions: Timer, DATA HOLD, automatic shutdown.
CA 5231 Multimeter (TRMS)
This compact digital multimeter meets all the requirements of craftsmen in the electrical industry excellent.
This easy-to-use device offers optimum readability with 6,000-point bar graph and backlight.
The two off positions allow faster working, with non-contact voltage detection possible in an off position. The screen turns red when the device is held near a live conductor.
You can measure voltages up to 600 A with the supplied clamp-on ammeter compliance with all safety regulations.
CA 762 Voltage tester
The voltage tester (VAT) CA 762 is an essential tool for any electrician to check if there is enough power before any interference into an electrical system connected to the mains. It meets the standard IEC 61243-3 output 3 and can therefore be used in all outdoor and indoor systems of category 600 V CAT IV. In order to comply with certain standards and regulations applicable in some countries, there are two order numbers - with and without IP2X accessories. The CA 762 has a redundant safety system with the ELV LED, which flashes when a voltage of more than 50 VAC or 120 VDC is present.
A comprehensive self-test of the CA 762 tests the electrical circuits, the power supply, the displays and the correct condition of the test leads. The test tip and the cables can be removed. With the optional adapter CA 753, you can test on earthing-contact sockets quickly and easily.
LM 76 Luxmeter
The LM 76 Luxmeter is very easy to use. The probe for measuring the illuminance level is removable, enabling a flexible measurement.
The unit can be changed between Lux and FC. The measuring device offers the functions MAX, MIN and HOLD. For the measurement range from 0 to 200,000 Lux an accuracy of 3% is guaranteed.
The measured values displayed include the compensation of the spectral error.
RPM 82 digital tachometer
The Multimatrix RPM 82 is a very easy to use digital tachometer. It is used to measure rotational speeds with or without contact.
Non-contact speed measurement is performed using reflective tape that is applied to the object to be measured.
For measuring the speed with contact, the user can choose to measure the revolutions per minute or the surface speed.
You can save the measured values. Pressing and holding the memory button during the measurement saves the device the last, maximum and minimum value of the time period when it is released. These can then be retrieved immediately after the measurement.
CM 625 multiple soldering pliers
The Multimetric multiple clip-on ammeters are equipped with all the functions of a current clamp and a full-on multimeter. They are the ideal work devices for every electrician and technician.
The compact and ergonomic model CM 625 is especially meant for applications on smaller electrical installations. The multimeter CM 625 offers the HOLD function and TRMS measurements.
VT 35 socket and FI tester
The Multimatrix VT 35 is a very easy to use tester for sockets and FI-protection switch (10 mA and 30 mA).
It can test FI circuit-breaker from 10 to 35 mA. The connection is done quickly and easily via the socket.
In addition, the following tests can be carried out:
No phase, no earth, no neutral wire
Reverse phase/neutral conductor and phase/earth
FIT-100 FI/RCD TESTER
Locking and warning signals for 400 V mains voltage and contact potential below 50 V.
Resistance to mechanical shocks: 1J
Works on a TT neutral conductor and TN system
Double insulation
Automatic switch off function
Display for weak battery
This text is machine translated.
Scope of delivery
- MH 401 Insulation measuring device
- CA 5231 Multimeter (TRMS)
- CA 762 Voltage tester
- LM 76 Luxmeter
- RPM 82 digital tachometer
- CM 625 multiple soldering pliers
- VT 35 socket and FI tester
- FIT-100 FI/RCD TESTER
