circuit breaker ABB 2CSM204693R1801
Product type
circuit breaker
Number of pins
1
Nominal voltage
1000 V
Mounting method
DIN rail
Lockable
TRUE
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
circuit breaker
- Number of pins
1
1000 V
DIN rail
TRUE
64 mm
1
1
IP20
TRUE
TRUE
10x38 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3118921 circuit breaker ABB 2CSM204693R1801
User & Safety Instructions
User & Safety Instructions 3118921 circuit breaker ABB 2CSM204693R1801
Description
E 90 PV fuse disconnect switches are designed for operating voltages of 1000 VDC with usage category DC-20B and are particularly suitable for over-current protection of photovoltaic systems. The 1-pin or 2-pin E 90 PV fuse disconnector for cylindrical fuses with 10.3 x 38 mm offer a reliable, compact and economical solution for photovoltaic systems. Versions with fuse failure indicator enable an inspection of the functionality of the fuse.
