Contrinex Inductive proximity switch shielded PNP DW-AS-604-065-001
Product type
Inductive proximity switch
Max. operating voltage
30 V
Outputs
PNP
Switching distance (max.)
1.5 mm
Connector
M8 connector
Datasheet (PDF)
Part number:
Item no:
Technical specifications
- Product type
Inductive proximity switch
- Type
DW-AS-604-065-001
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Outputs
PNP
- Switching distance (max.)
1.5 mm
- Connector
M8 connector
- Installation type
shielded
- Enclosure material
Metal
- Length
45 mm
- Width
6.5 mm
- Height
45 mm
- (Ø)
6.5 mm
- Dim
(Ø x H) 6.5 mm x 45 mm
- Type
Smooth cylinder
Documents & Downloads
Datasheet
Datasheet 3819573 Contrinex Inductive proximity switch shielded PNP DW-AS-604-065-001
User & Safety Instructions
User & Safety Instructions 3819573 Contrinex Inductive proximity switch shielded PNP DW-AS-604-065-001
Description
Inductive sensor, diameter 6.5 mm, switching distance 1.5 mm, flush mounted, standard design, Length 45 mm (plug), stainless steel V2A, operating voltage 10 ... 30 VDC, output current 200 mA, LED, short-circuit protection, induction protection, Integrated polarity reversal protection, PNP version NC, connection S8
