Cooler Master RR-212S-25PZ-R1 CPU cooler + fan Intel® 1150, Intel® 1151, Intel® 1155, Intel® 1156, Intel® 1200, Intel® 1
EAN:
Part number:
Item no:
Highlights & Details
Cooler Master RR-212S-25PZ-R1 CPU cooler + fan
- Processor air cooling 12 cm 2500 RPM
- LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5
- 32.8 dB 70.7 cfm 3.61 mmH2O Loop Dynamic Bearing (LDB) (loop dynamic bearing)
- Support for pulse width modulation
- 120 x 120 x 25mm
- Black
- This text is machine translated.
Technical specifications
- Fan diameter 12 cm
- LGA 1150 (Socket H3),LGA 1151 (Socket H4),LGA 1155 (Socket H2),LGA 1156 (Socket H),LGA 1200 (Socket H5),LGA 1700,Socket AM4,Socket AM5
- Bearing type: Loop Dynamic Bearing (LDB) (loop dynamic bearing)
- Number of fans: 1 fans
- 4-pin fan connector
- Product type
CPU cooler + fan
Intel® 1150
Intel® 1151
Intel® 1155
Intel® 1156
Intel® 1200
Intel® 1700
AMD AM4
#####AMD AM5
- Noise emission (max.)
32.8 dB
- Rotational speed (min.)
690 U/min
- Rotational speed (max.)
2500 U/min
- Air discharge
120 m³/h
- Connection
4-pin
- Weight
700 g
- Width
74 mm
- Height
152 mm
- Depth
125 mm
- Noise emission
30.1 dB - 40 dB
- Fan dimensions
120 x 120 mm
- Factory colour
Black
- Type
Air cooling
- UKCA
yes
- Number of heat pipes
4
- Illumination LED
yes
- Fan dimensions (W x D x H)
120 x 120 x 25 mm
- Rated voltage
12 V
- Master (outer) case length
500 mm
- Products per master (outer) case
8 Stück(e)
- Fan power consumption
2.4 W
- Pulse-width modulation (PWM) support
yes
- Rated current
0.2 A
- Fan's mean time to failure (MTTF)
160000 h
- Safety current
0.3 Ah
- Master (outer) case height
210 mm
- Master (outer) case width
310 mm
- Package weight
890 g
- Maximum airflow
70.7 cfm
- Maximum air pressure
3.61 mmwc
