Counttec eHz Electricity meter (3-phase) Refurbished (good) Digital 1 pc(s)
EAN:
Part number:
Item no:
Product type
Electricity meter (3-phase)
Display
Digital
Operating voltage
230 V. 3 x 230/400 V
Special feature
Can also be used in 230 V AC power supplies
Dim
(L x W x H) 78 x 90 x 135 mm
Datasheet (PDF)
Highlights & Details
Regenerated electronic household meter
- Modern measuring equipment
- EDL-design in accordance with FNN-load specifications
- Historical values for the last 24 months
- High resistance to external magnetic fields
Technical specifications
- Measurement modes: Setup counter +A or -A with reverse lock or double direction counter +A and -A or totalizing counter -A without reverse lock
- Impulse values LED (IR): 10 000 Imp./kWh 100 000 imp./kWh
- Data interface 2x optical
- Operating temperature range: -40°C...+70°C.
- Protection class: II
- IP 51 enclosure rating
- Housing material: Polycarbonate glass-fiber reinforced. halogen-free. recyclable
- Product type
Electricity meter (3-phase)
- Display
Digital
- Operating voltage
230 V. 3 x 230/400 V
- Special feature
Can also be used in 230 V AC power supplies
- Dim
(L x W x H) 78 x 90 x 135 mm
- Weight
400 g
Refurbished (good)
- Condition
The product shows some slight imperfections in the form of scratches or small dents. However, these imperfections do not affect product functionality.
- Display
2-line LCD display
8 mm (value range)
- Recording time (max.) (details)
spannungslos im EEPROM. mind. 20 Jahre
- Self-consumption
1.2 W
- Own consumption
Voltage path < 1.2 W. Current path < 0.05 VA
- Recess width
90
- Recess length
135
- Frequency
50 Hz
- Accuracy class
CI.A
- Reading type
Amperage
- Nominal voltage range
230 up to 400 V AC
- Mains voltage (max.)
400 V AC
- Mains voltage (min.)
230 V
- Width
90 mm
- Height
135 mm
- Length
78 mm
- Current (max.)
300 A
- Current (min.)
0.25 A
- Current range
0.25 up to 300 A
- Type
eHz
Documents & Downloads
Datasheet
Datasheet 2997953 Counttec eHz Electricity meter (3-phase) Refurbished (good) Digital 1 pc(s)
Description
Only for internal measurements without PIN
