Crouzet 88974051 Millenium 3 Smart CD20 R PLC controller 24 V DC
EAN:
Part number:
Item no:
Total (€ 429.00 / piece)
€ 429.00
incl. VAT
14-day return policy included
Highlights & Details
Crouzet Millennium 3 controllers
- Modular versions designed for application-specific functions
- LCD with 4 lines of 18 characters and configurable backlighting
Technical specifications
- Product type
PLC controller
- Operating voltage
24 V DC
- Display
Yes
- Type
Millenium 3 Smart CD20 R
- Min. ambient temperature
-25 °C
- Max. ambient temperature
55 °C
- Manufacturer part #
88974051
- Dim
(L x W x H) 59.5 x 124.6 x 90 mm
- No. of outputs (max.)
8
- No. of inputs (max.)
12
- No. of relay outputs (max.)
8
- No. of analogue inputs
4
- No. of digital inputs (max.)
12
- Operating voltage
28.8 V DC (max)
- Max. operating voltage
28.8 V DC
- Width
124.6 mm
- Height
90 mm
- Length
59.5 mm
- Digital outputs
8 outputs relay 8 A
- Digital inputs
12 (4 analog)
- Operating voltage
24 V DC
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 197591 Crouzet 88974051 Millenium 3 Smart CD20 R PLC controller 24 V DC
Description
Custom controls have additional features such as adaptive control, burner control systems, light measurement, direct connection of NTC resistors to the integrated analog inputs, arbitrary curves and ramps "y = f (x)" (enter the transfer function in EXCEL). These functions enable many additional applications in engineering, building technology, heating and cooling, greenhouses, water treatment are just some examples.
