Crunch DSX62 2-way coaxial flush mount speaker kit 180 W Content: 1 pc(s)
EAN:
Part number:
Item no:
Highlights & Details
Crunch coax 16.5 cm DSX-62
- Stable steel baskets in flat designInner magnetic drivePolypropylene membranes
Technical specifications
- Max. audio capacity
180 W
- Product type
2-way coaxial flush mount speaker kit
- RMS capacity
90 W
- Frequency range
65 - 22000 Hz
- Recess diameter
145 mm
- Recess depth
45 mm
- Impedance
4 Ω
- Content
1 pc(s)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2799453 Crunch DSX62 2-way coaxial flush mount speaker kit 180 W Content: 1 pc(s)
Description
The loudspeakers of THE Crunch DSX series in flat design are equipped with special, inner-lying magnet systems. The extremely flat chassis with high capacity 25 mm voice coils is the first choice for space-saving installations thanks to its special design. Due to their low mounting depth they are especially suitable for Ideal vehicles, where the installation space is limited or the sound system speakers have to be replaced ex works.
This text is machine translated.
This text is machine translated.
Features
- 25 mm voice coilsRobust speaker grille2 x 165 mm mid-range speaker with 13 mm Mylar-Neodymium tweeterLoad capacity 90 Watt RMS Maximum load capacity 180 watt Max Impedance: 4 ΩFrequency range 65 22000 HzMounting hole 145 mm.Mounting depth 45 mm
