Current monitor relay 110 - 130 V AC 1 change-over ABB CM-SRS.11P 1 pc(s)
Product type
Current monitor relay
Functions
Current
Max. operating voltage
130 V AC
Contact type
1 change-over
Type
CM-SRS.11P
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Current monitor relay
- Type
CM-SRS.11P
- Functions
Current
- Min. operating voltage
110 V AC
- Max. operating voltage
130 V AC
- Operating voltage
110 - 130 V AC
- Amperage adjustment range (min.)
3 mA
- Amperage adjustment range (max.)
15 A
- Adjustment range (amperage)
3 - 15 A
- Contact type
1 change-over
- Connection
Spring-loaded connector
- Width
22.5 mm
- Height
85.6 mm
- Depth
103.7 mm
- Dim
(W x H x D) 22.5 x 85.6 x 103.7 mm
- Content
1 pc(s)
22.5
78 mm
103 mm
0.1-1 A
FALSE
FALSE
TRUE
FALSE
TRUE
FALSE
TRUE
FALSE
TRUE
TRUE
TRUE
Spring clamp connection
110-130 V
110-130 V
0 s
0 s
0 s
0 s
AC
0
0
1
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3103990 Current monitor relay 110 - 130 V AC 1 change-over ABB CM-SRS.11P 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3103990 Current monitor relay 110 - 130 V AC 1 change-over ABB CM-SRS.11P 1 pc(s)
Description
The current monitoring relays of the CM series protect single-phase networks (DC or AC)
Over and undercurrents between 3 mA and 15 A. The devices with the maximum measurement range
Of 1 A are available in two different connection versions. You have the choice
Between the proven screw connection technology (double-chamber-box-terminals)
And the tool-less Easy Connect connection technology (push-in terminals). Devices
With a measuring range of maximum 15 A, screw connection technology is available.
This text is machine translated.
Over and undercurrents between 3 mA and 15 A. The devices with the maximum measurement range
Of 1 A are available in two different connection versions. You have the choice
Between the proven screw connection technology (double-chamber-box-terminals)
And the tool-less Easy Connect connection technology (push-in terminals). Devices
With a measuring range of maximum 15 A, screw connection technology is available.
This text is machine translated.
