Name: DEHN 102340 BES 17KG KT16 ULP D337 SET Concrete base 1 pc(s)
Brand: DEHN
SKU: 2750007

Round, grey concrete slab with notches and a central anchor, possibly a foundation block for tent poles or parasols.

Technical drawing of a round container with dimensions: diameter 337 mm, depth 40 mm. Additional details such as height and positions specified.

1/2

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Concrete base

Manufacturer part #: 102340

Content: 1 pc(s)

: Base

: 17 kg

: 337 mm

: Concrete

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2750007 DEHN 102340 BES 17KG KT16 ULP D337 SET Concrete base 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2750007 DEHN 102340 BES 17KG KT16 ULP D337 SET Concrete base 1 pc(s)

Information

Information 2750007 DEHN 102340 BES 17KG KT16 ULP D337 SET Concrete base 1 pc(s)

Description

Concrete base for catching bars, for protecting small roof structures on flat roofs and for building distance holders e.g. B. For separate ring loops or free standing catching rods in the tripod stand (only with weight of 17 kg). Stackable design and adapted underplate, for catching rods Rd 16 mm, chamfered, tapered or DEHNISO-distance holder Rd 16 mm

This text is machine translated.
