Name: DEHN 105351 DBS KB D50 RA620 STTZN Triopd (adjustable height) 1 pc(s)
Brand: DEHN
SKU: 2750653

Metallic tripod mount with adjustable legs and central pipe connection, used for antenna or mast installation.

Technical drawing of a three-legged tripod with dimensions and details of screws and distances. Top view above, side view below.

1/2

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Triopd (adjustable height)

Manufacturer part #: 105351

Content: 1 pc(s)

: Tripod

: Hot-dip galvanized

: 11.5 kg

: 1240 mm

: Steel

UKCA: not relevant

Documents & Downloads

Datasheet

Datasheet 2750653 DEHN 105351 DBS KB D50 RA620 STTZN Triopd (adjustable height) 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2750653 DEHN 105351 DBS KB D50 RA620 STTZN Triopd (adjustable height) 1 pc(s)

Information

Information 2750653 DEHN 105351 DBS KB D50 RA620 STTZN Triopd (adjustable height) 1 pc(s)

Description

Tripod stand for the free construction of support tubes DEHNISO-Combi (D50 length 3200 mm). For installation with concrete bases with wedge technology, without additional attachment to construction elements. With adaptation to the roof inclination up to max. 10°. Design folding, especially for the inner laid HVI cable in the support pipe. To maintain the bend radius of the HVI cable at the bottom of the tripod stand, two concrete bases are positioned below the leg and one above.

This text is machine translated.
