DEHN 478011 EFPM M10 12 V4A L230 STTZN Earth anchor 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Diameter: 80 mm connection plate
- Diameter Connection Axis: 10 mm
- Product type
Earth anchor
- Manufacturer part #
478011
- Standards
DIN EN 62561-1
- Dim
(L x W x H) 180 x 232.0000 x 86.0000 mm
- Length
180 mm
- Width
232.0000 mm
- Height
86.0000 mm
- Depth
86.0000 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1968081 DEHN 478011 EFPM M10 12 V4A L230 STTZN Earth anchor 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1968081 DEHN 478011 EFPM M10 12 V4A L230 STTZN Earth anchor 1 pc(s)
Description
According to DIN EN 62561-1 earth fixed point, as corrosion free connection of the derivation, for example, to the reinforcement of buildings or to the earthing system, for the protection potential compensation and/or the function equipotential bonding for installation in the formwork. Type M with connection axle (10 mm) and connecting thread M10/12.
