DEHN 767640 Voltage tester Visual
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Application area: Interior and open air systems
- Display type: Optical
- Nominal voltage 0.6-0.75 kV
- Total length 1085.0-1085.0 mm
- Product type
Voltage tester
- Reading type
Voltage testing
- Display
Visual
- V DC reading range
0.6 up to 0.75 kV
Manufacturer's standards (no certificate)
- Voltage DC reading range (max.)
0.75 kV
- Voltage reading range DC (min.)
0.6 kV
- Length
1085.0 mm
- Type
767640
- Type
2-pin
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3801349 DEHN 767640 Voltage tester Visual
User & Safety Instructions
User & Safety Instructions 3801349 DEHN 767640 Voltage tester Visual
Description
Resistive, double-sided DC voltage tester PHE/G for switchgear, design positive pole on the test head, as an associated design based on DIN VDE 0682-411 (EN/IEC 61243-1) for determining the absence of voltage by touching at the working place according to DIN VDE 0105-100 (EN 50110-1) in electrical systems up to 750 V DC. Can also be used in precipitation.
This text is machine translated.
This text is machine translated.
Accessories
(*All information is plus legal VAT)The necessary accessories are required to use the article as described.
