DEHN 773330 UK 30 SQ Universal clamp 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product type
Universal clamp
- Manufacturer part #
773330
- Content
1 pc(s)
Phase-side
Fixed ball point 25 mm
30.0-30.0 mm
33.5 kA
16.0-120.0 mm²
TRUE
Spindle with cross pin
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2750484 DEHN 773330 UK 30 SQ Universal clamp 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2750484 DEHN 773330 UK 30 SQ Universal clamp 1 pc(s)
Information
Information 2750484 DEHN 773330 UK 30 SQ Universal clamp 1 pc(s)
Description
Universal terminal, spindle with cross-pin as phase-side or earthing-side connecting element according to DIN VDE 0683-100 (EN/IEC 61230) for ball fixed points, T-fixed points, flat and round conductor for assembling earthing and short-circuit cables. With rotation protection PK 1.
