DEHN 952512 DG M YPV SCI 1200 Surge arrester 12.5 kA 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Design of the poles: 2
- Size: 3 HP
- Integrated fuse: No.
- Short-circuit proof: Yes
- Max. Conductor cross-section flexible fine-strand 25 mm²
- Max. Conductor cross-section rigid single/multi-strand 35 mm²
- Max. PV voltage 1200 V.
- With remote signaling contact: No.
- Mounting type: DIN rail 35 mm
- Protection level 4.5 kV
- Signaling on the device: Optical
- Product type
Surge arrester
- Leakage current
12.5 kA
IP20
- Manufacturer part #
952512
- Type
2
- Compatible with (details)
Power technology/power supply
- Standards
EN 50539-11
- Content
1 pc(s)
- UKCA
not relevant
