Deko Light Highbay Normae 732085 LED hall light EEC: G (A - G) LED (monochrome) Built-in LED 190 W Dark grey
EAN:
Part number:
Item no:
Technical specifications
- Activation: DALI bus according to IEC 62386 DALI 1.0
- Dimensions diameter (mm):
- Base length (mm): 110
- Socket width (mm): 70
- Socket height (mm): 95
- Assembly pot diameter 1 (mm):
- Light source: Inclusive light source
- Colour rendering Ra: 80
- Light intensity 12040 cd
- Durability: 40000 h
- Switching cycles 10000
- Radiation distribution 570 nm
- Number of LEDs: 236
- LED type SMD
- LED design M3DH
- Terminal connection option
- Inclination 180°
- Material 2: Plastic
- Optics 2: Clear / satin
- Product type
LED hall light
- Operating voltage
100 V AC
240 V AC
- No. of bulbs
236
- Bulb type
LED (monochrome)
Built-in LED
- Rating per bulb
190 W
190 W
- Energy consumption
190 kWh/1000h
5000 K
- Colour
Neutral white
- Total luminous flux
23800 lm
- Light features
Swivelling
- Swivel range (max.)
180°
- Protection class
I
IP65
- Factory colour
Dark grey
- Material
Aluminium (die-cast)
- Dim
(W x H x D) 126 x 99 x 1219 mm
G (A - G)
- Colour temperature range
5000 K
- Width
126 mm
- Height
99 mm
- Depth
1219 mm
- Radiation angle
90°
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2795241 Deko Light Highbay Normae 732085 LED hall light EEC: G (A - G) LED (monochrome) Built-in LED 190 W Dark grey
Description
The energy-efficient HIGHBAY spotlights are ideal for hall lighting. Thanks to the adjustable mounting set the spotlights can be mounted in the desired angle of inclination. With the appropriate set additionally results in the option to suspend it as well as, if necessary, to equip it with asymmetric lenses.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Inc. adjustable fixing setDALI STANDARDS IEC62386-101, 102, 207
