Delock 12421 Internal antenna GSM
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
GSM Antenna SMA Plug Screw mount 3 dBi omnidirectional emission with magnetic base and connection cable RG-174 3 m outdoor black
Technical specifications
- Cable type: RG-174
- Product type
Mobile phone antenna
- Mobile phone standard
GSM
UMTS
- Factory colour
Black
- Gain
3 dBi
- Length
150 cm
- Antenna type
Internal antenna
- Suitable for mains
GSM
- Width
50 mm
- Height
138 mm
- Cable design
Round
- Cable length
3 m
- Version
Cable
- Depth
50 mm
- Cable use
C13/C14 appliances
- Weight
0.15
- UKCA
yes
- Operating temperature (T-T)
-30 - 70 °C
- Antenna gain level (max)
3 dBi
- Impedance
50 Ohm
- Quantity per pack
1 Stück(e)
- Maximum cable loss with connectors
1.5 dB
- Power handling
10 W
Documents & Downloads
Datasheet
Datasheet 3381160 Delock 12421 Internal antenna GSM
User & Safety Instructions
User & Safety Instructions 3381160 Delock 12421 Internal antenna GSM
Description
This GSM antenna from Delock enables the use of different GSM bands indoors and outdoors. It is fully compatible with GSM, UMTS, ZigBee 868 MHz / 915 MHz, DECT, Z-Wave and LoRa 868 MHz / 915 MHz.
This text is machine translated.
This text is machine translated.
Features
- Connection 1 x SMA plug
- Frequency range:
- 824 - 960 MHz
- 1710 - 2170 MHz
- GSM, UMTS, ZigBee 868 MHz / 915 MHz, DECT, Z-Wave, LoRa 868 MHz / 915 MHz
- Antenna gain 3 dBi
- Impedance: 50 ohm
- Polarisation: linear, vertical
- VSWR: ≤2.0
- Transmitted power 10 W
- Operating temperature: -30 °C ~ 70 °C
- Colour, black
- Antenna length incl. magnetic base: Approx. 13.8 cm
- Cable type: Coaxial
- Cable type: RG-174
- Cable color: Black
- Cable attenuation: 1.5 dB @ 1.5 GHz per meter
- Cable diameter: Approx. 2.7 mm
- Cable length incl. connection: Approx. 3 m.
- Antenna length incl. magnetic base: Approx. 13.8 cm
- Diameter of magnetic base: Approx. 50.0 mm
System requirements
- Device with a free SMA socket
