Delock 12697 Internal antenna GSM, UMTS
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
GSM, UMTS Antenna N socket 2 dBi 17.8 cm omnidirectional rigid with flexible materials outdoor black
Technical specifications
- Product type
Mobile phone antenna
- Mobile phone standard
GSM
UMTS
- Factory colour
Black
- Gain
2 dBi
- Antenna type
Internal antenna
- Suitable for mains
GSM
UMTS
- Width
2 cm
- Height
17.8 cm
- Cable design
Round
- Version
Cable
- Cable use
C13/C14 appliances
- Weight
150 g
- UKCA
yes
- Operating temperature (T-T)
-40 - 80 °C
- Antenna gain level (max)
2 dBi
- Impedance
50 Ohm
- Quantity per pack
1 Stück(e)
- Diameter
2 cm
- Power handling
50 W
Documents & Downloads
Datasheet
Datasheet 3382099 Delock 12697 Internal antenna GSM, UMTS
User & Safety Instructions
User & Safety Instructions 3382099 Delock 12697 Internal antenna GSM, UMTS
Description
The Delock antenna allows the use of GSM, UMTS bands indoors and outdoors.
This text is machine translated.
This text is machine translated.
Features
- 1 x N socket
- Frequency range:
- 824 - 960 MHz
- 1710 - 2170 MHz
- Antenna gain 2 dBi
- Impedance: 50 ohm
- Polarisation: Vertical
- VSWR 2.5
- Transmitted power 50 W max.
- Operating temperature: -40 °C ~ 80 °C
- Dimensions (LxD): Approx. 17.8 x 2.0 cm
- Weight approx. 150 g
System requirements
- Device with an empty N connection
