DEVI 140F1139 140F1139 Controller DIN rail 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Controller
- Operation type
electronical
- Remote sensor
Yes
- Mounting type
DIN rail
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3136700 DEVI 140F1139 140F1139 Controller DIN rail 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3136700 DEVI 140F1139 140F1139 Controller DIN rail 1 pc(s)
Description
Electronic, programmable 7-channel control. Each channel can be separately included
Three control modes can be set up with temperature sensor, time-proportional
Power control without sensor and manual on/off switching with time limitation.
The channel inputs can be selected by software between 8 types of temperature sensors
Including NTC 15 kOhm at 25°C. The opto-isolated serial Modbus interface
RS485 offers the possibility for BMS control. Mounting DIN rail, according to EN 60715, voltage: 85 - 250 V, 50 - 60 Hz, protection class: IP40 only on front cover- line sensor type: 15 kOhm at 25°C.
This text is machine translated.
Three control modes can be set up with temperature sensor, time-proportional
Power control without sensor and manual on/off switching with time limitation.
The channel inputs can be selected by software between 8 types of temperature sensors
Including NTC 15 kOhm at 25°C. The opto-isolated serial Modbus interface
RS485 offers the possibility for BMS control. Mounting DIN rail, according to EN 60715, voltage: 85 - 250 V, 50 - 60 Hz, protection class: IP40 only on front cover- line sensor type: 15 kOhm at 25°C.
This text is machine translated.
