di-soric 212922 LED spot lighting
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Light color: Red
- Product type
LED spot lighting
- Protection class
III
IP67
n.rel.
- Width
32 mm
III
32 mm
DC
21 mm
30 mm
LED not exchangeable
IP67
TRUE
2.8 W
Red
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 3816635 di-soric 212922 LED spot lighting
User & Safety Instructions
User & Safety Instructions 3816635 di-soric 212922 LED spot lighting
Description
Spot lighting Transmission light source: LED Light color: Red, 634 nm Radiation angle FWHM: 7° Operating voltage: 18 . 30 V DC Idle current (max.): 115 mA (24 V DC) Housing material: Aluminium, black (anodized) Ambient temperature Operation: 0 . +40 °C Protection class: IP 67 Protection class III, operation at protection extra low voltage Connection: Plug, M12, 3-pin
