Doepke 09156901 DFS4 080-4/0,30-A 4polig 80/0,3A RCCB A 4-pin 80 A 0.3 A 230 V, 400 V
EAN:
Part number:
Item no:
Product type
RCCB
Number of pins
4
Release characteristics
A
Differential current rating
0.3 A
Nominal current - rounded value
80 A
Datasheet (PDF)
Highlights & Details
DOEPKE FI-switch, four-pole, 80 A, 0.30 A, Type A, N links
- Quick mounting on DIN rail
- All mounting positions permitted
- Feed direction
Technical specifications
- Product type
RCCB
- Number of pins
4
- Release characteristics
A
- Differential current rating
0.3 A
- Nominal current
80 A
- Nominal current - rounded value
80 A
- Dim
(W x H x D) 72 x 85 x 75 mm
- Content
1 pc(s)
- Nominal voltage
230 V
400 V
- Width
72 mm
- Height
85 mm
- Depth
75 mm
- Weight
0.42
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2136360 Doepke 09156901 DFS4 080-4/0,30-A 4polig 80/0,3A RCCB A 4-pin 80 A 0.3 A 230 V, 400 V
User & Safety Instructions
User & Safety Instructions 2136360 Doepke 09156901 DFS4 080-4/0,30-A 4polig 80/0,3A RCCB A 4-pin 80 A 0.3 A 230 V, 400 V
Description
Residual current circuit breaker (RCCB) Switch the power supply whenever dangerously high fault currents. You protect people, animals and plants. DFS 4 are two- or four-pole residual current protective switch for single-phase or three-phase systems. In the standard version, the compact devices four division units narrow. They are equipped with many different fault current types and versions with rated currents up to 125 A available. The large Double level terminals can also be large conductor cross-section. The triggered position of the multi-function knob simplifies troubleshooting. The free label software helps with the label. Switch of the type A are pulse and alternating current and sensitive. This function is independent of mains voltage. Devices are in the standard version for the monitoring of circuits with a rated voltage of 230V/400V and a rated frequency of 50 Hz.
