Image similar
Dold 0039409 BA7924.21 DC24V 1-10s TDR Multifunction 24 V DC 1 pc(s) Time range: 1 - 20 s 2 breakers, 1 maker Piece
Packaging type
Piece
Product type
TDR
Type
Multifunction
Functions
Off-delay
Operating voltage
24 V DC
Datasheet (PDF)
EAN:
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Technical specifications
- Packaging type
Piece
- Product type
TDR
- Type
BA7924.21 DC24V 1-10s
- Type
Multifunction
- Connection
Screw terminal
- Functions
Off-delay
- Operating voltage
24 V DC
- Contact type
2 breakers
1 maker
- Switching voltage (max.)
230 V AC
- Switching current (max.)
8 A
- Time range (min.)
1 s
- Time range (max.)
20 s
- Time range(s)
20 s
- Min. temperature
-20 °C
- Max. temperature
+60 °C
IP20
IP40
- Electrical lifespan
6 A, AC 230 V cos ϕ = 1 : > 2 x 105 switching cycles
- Durability
50 x 106 operations
- Width
45 mm
- Height
74 mm
- Depth
133 mm
- Dim
(W x H x D) 45 x 74 x 133 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2359266 Dold 0039409 BA7924.21 DC24V 1-10s TDR Multifunction 24 V DC 1 pc(s) Time range: 1 - 20 s 2 breakers, 1 maker Piece
User & Safety Instructions
User & Safety Instructions 2359266 Dold 0039409 BA7924.21 DC24V 1-10s TDR Multifunction 24 V DC 1 pc(s) Time range: 1 - 20 s 2 breakers, 1 maker Piece
Description
Delayed shut-offs with a selectable switching state of the output relays.
· Corresponds to
Performance level (PL) c and category 2 according to EN ISO 13849-1
SIL CLAIM LIMIT (SIL CL) 2 · According to IEC/EN 62061
Safety Integrity Level (SIL) 2 · According to IEC/EN 61508 and IEC/EN 61511
· Delayed drop off
· Without auxiliary voltage
· Output: 1 NC contact, 1 NO forced action
· Switch position indicator
· 45 mm width
This text is machine translated.
· Corresponds to
Performance level (PL) c and category 2 according to EN ISO 13849-1
SIL CLAIM LIMIT (SIL CL) 2 · According to IEC/EN 62061
Safety Integrity Level (SIL) 2 · According to IEC/EN 61508 and IEC/EN 61511
· Delayed drop off
· Without auxiliary voltage
· Output: 1 NC contact, 1 NO forced action
· Switch position indicator
· 45 mm width
This text is machine translated.
