Eaton 242543 PLSM-C16/3N-MW Circuit breaker 3-pin 16 A 400 V AC
Product type
Circuit breaker
Number of pins
3
Release characteristics
C
Nominal current - rounded value
16 A
Type
No. of pins 3 + N
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Circuit breaker switch
- Switch position indicator red/green
- Guide for secure terminal connection
- Rated breaking capacity 10 kA in accordance with IEC/EN 60898-1
- Extensive additional equipment suitable for subsequent installation
- High selectivity between miniature circuit breakers and pre-fuse due to low flow energy
- Meets insulation coordination requirements, distance between contacts ≥ 4 mm, for secure insulation
Technical specifications
- Connectable conductor cross-section, multi-strand: 1 - 25 mm²
- Connectable conductor cross-section single-wire: 1 - 25 mm²
- Number of poles secured: 3
- Type
No. of pins 3 + N
- Product type
Circuit breaker
- Number of pins
3
- Release characteristics
C
- Nominal current - rounded value
16 A
- Nominal current
16 A
- Dim
(W x H x D) 70 x 80 x 70.5 mm
- Content
1 pc(s)
- Nominal voltage
400 V AC
- Width
70 mm
- Height
80 mm
- Depth
70.5 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2290571 Eaton 242543 PLSM-C16/3N-MW Circuit breaker 3-pin 16 A 400 V AC
User & Safety Instructions
User & Safety Instructions 2290571 Eaton 242543 PLSM-C16/3N-MW Circuit breaker 3-pin 16 A 400 V AC
Description
Leitungsschutzschalter Xpole for residential/commercial applicationsMoeller® series
versatile circuit breakers with a guide for secure terminal connection and compatible with standard busbars, which can be arranged at the top or bottom.
This text is machine translated.
versatile circuit breakers with a guide for secure terminal connection and compatible with standard busbars, which can be arranged at the top or bottom.
