Elmeko Enclosure thermostat TES 60 24 V DC 1 change-over (L x W x H) 37 x 64 x 46 mm 1 pc(s)
EAN:
Part number:
Item no:
Product type
Enclosure thermostat
Connection
Screw terminal
Contact type
1 change-over
Operating voltage
24 V DC
Type
TES 60
Datasheet (PDF)
Highlights & Details
- For Peltier cooling devices and heaters
- High DC switching capacity
- Small hysteresis
- Adjustable temperature 0 – 60°C.
- Changeover contact
- Mounting on DIN rail
- This text is machine translated.
Technical specifications
- Switching capacity: Max. 16 A
- Power consumption: 0.75 W
- Colors RAL: RAL 7035
- Output: Relay with potential
- operating temperature: -10 °C - +70 °C
- Storage temperature: -20 °C - +70 °C
- Hysteresis: Approx. 2 K - 3 K
- Permissible humidity: Max. 95%RH, non-dew
- Temperature sensor: Internal NTC
- Weight: 70 g
- Protection class: ΙΙΙ
- Material : Polyamide PA 6.6
- Mounting: DIN standard rail 35 mm
- Product type
Enclosure thermostat
- Type
TES 60
- Connection
Screw terminal
- Adjustment range (min.) (temperature)
0 °C
- Temperature adjustment range (max.)
+60 °C
- Factory colour
Light grey
- Mounting type
DIN rail
- Contact type
1 change-over
- Operating voltage
24 V DC
- Operating temperature (min.)
-10 °C
- Operating temperature (max.)
+70 °C
- Length
37 mm
- Width
64 mm
- Height
46 mm
- Dim
(L x W x H) 37 x 64 x 46 mm
IP20
- UKCA
yes
