Elmeko MSE 40, 24 V DC, 64 W Dehumidifier 24 V DC 64 W (W x H x D) 113.5 x 195 x 96 mm Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Dehumidifier
Operating voltage
24 V DC
Power
64 W
Noise emission (max.)
65 dBa
Datasheet (PDF)
Highlights & Details
ELMEKO MSE 40 DEHUMIDIFIER, 24 V DC, 64 W
- Integrated humidity control
- Mounting on rail
- High dehumidification performance
- Runtime monitoring with maintenance reminder
- Adjustable alarm functions
- RS485 interface
- Parameters can be set directly on the device or
- With software
- 5 V DC-output for ext. Solid state relay
- (E.g. for connecting a heater)
Technical specifications
- Dehumidifying output: Max. 550 ml / 24 h (35 °C, 85 % r.h.)
- Humidity measurement range: 0 % r.h. … 100 % r.h.
- Measuring accuracy ±2 % r.h.
- Setting range for dehumidification: Starting value: 2 … 99 % r.h. / Stop value: 1 … 98 % r.h.
- Adjustment range heating (5 V DC output for relays): Start value: -30 … +40 °C / Stop value: -20 … +50 °C
- Packaging type
Piece
- Product type
Dehumidifier
- Type
MSE 40, 24 V DC, 64 W
- Features
incl. software
- Operating voltage
24 V DC
- Max. current consumption
2.7 A
64 W
- Noise emission (max.)
65 dBa
- Factory colour
Black
- Min. temperature
-30 °C
- Max. temperature
70 °C
IP20
- Connection
Jack connector
Screw terminal
- Width
113.5 mm
- Height
195 mm
- Depth
96 mm
- Dim
(W x H x D) 113.5 x 195 x 96 mm
- Weight
770 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3478406 Elmeko MSE 40, 24 V DC, 64 W Dehumidifier 24 V DC 64 W (W x H x D) 113.5 x 195 x 96 mm Piece 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3478406 Elmeko MSE 40, 24 V DC, 64 W Dehumidifier 24 V DC 64 W (W x H x D) 113.5 x 195 x 96 mm Piece 1 pc(s)
Description
Dehumidifier
MSE 40, 24 V DC, 64 W
Protection class: IP20
Dehumidifying output 550 ml / 24 h (35 °C, 85 % r.h.)
Hose for condensate drain 1 mtr.
For mounting on a DIN rail (interior mounting)
This text is machine translated.
MSE 40, 24 V DC, 64 W
Protection class: IP20
Dehumidifying output 550 ml / 24 h (35 °C, 85 % r.h.)
Hose for condensate drain 1 mtr.
For mounting on a DIN rail (interior mounting)
This text is machine translated.
Hints
Installation:
The equipment can either be fixed on a mounting rail TS 35 × 15 mm or with M4 screws through the holes provided in the device. It is essential to maintain a horizontal installation position with the hose connector pointing downwards, otherwise the device will not function properly. A distance of at least 80 mm to neighboring equipment must be maintained upward and forward in order not to affect the air inlet (upper side of the device) and the air outlet (front side). The condensate hose is pushed onto the hose connection at the bottom of the device and must be routed to the outside of a container below the device or through the cabinet wall. An OUT-FIT element from our accessories program is ideally used for this purpose.
