Eltako 61000164 SMPSU 12 V 1 A 6 W
EAN:
Part number:
Item no:
Highlights & Details
Switching power supply 12V DC
- Output 12 V / 1 A
- Power 6 W
- Screws
Technical specifications
- Product type
SMPSU
- Input voltage (max.)
230 V AC
- Max. output current
1 A
- Output current (max.) - rounded
1 A
- Min. input voltage
230 V AC
- Dim
(L x W x H) 33 x 45 x 45 mm
- Output voltage (max.)
12 V
- Connection
Screws
6 W
IP20
- Type
short circuit resistant
- PSU features
Adjustable voltage output
Regulated
- Width
45 mm
- Height
45 mm
- Length
33 mm
- Type
SNT61-230V/12VDC-0,5A
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3398408 Eltako 61000164 SMPSU 12 V 1 A 6 W
Description
Switched PSU Power rating 6W. Standby loss of only 0.1 watt. For panel mounting. 45 mm long, 45 mm wide, 33 mm deep. Input voltage 230V (-20% to +10%). Efficiency 81% Stabilised output voltage ±1%, low ripple. Short-circuit-proof. Overload and excess temperature protection by switching off with automatic switching after fault elimination (auto-recovery function).
